MAS MCV1000, v.n. 171

Machine newly built 2024, complete modernization to HH TNC620, new machine parameters, workpiece probe, central cooling.

Parameters:

spindle: MAS, 10000 rpm, ISO40

spindle motor: Siemens 1PH8 19.5 kW

control system: Heindenhain TNC620 HSCI, MC 8410 touch screen

workpiece/tool probe: YES, Heidenhain TS460

handweel: Heidenhain HR510FS

measurement, rulers: Heidenhain LC415, EnDat 2.2

feed motors: Heidenhain QSY

central tool cooling: YES, 20 bar Grundfos

external tool cooling: 10 bar, Grundfos

manual rinsing: spray gun at 10 bar

tool magazine: GIFU, 24-position drum

chip conveyor: NO, OPCE

linear guide: HIWIN

table clamping area: 1300 x 600 mm, T-slots 18.5 H7

max. table load: 700 kg

XYZW travel: 1000 x 600 x 660 mm

working air pressure: 6-7 bar

positioning accuracy: <0.01 mm

total machine dimensions: W 3000 x L 2700 x H 2940 mm

total machine weight: approx. 5500 kg

MAS MCV1000, v.č. 419

Machine newly built 2025, complete modernization to HH TNC620, new machine parameters, workpiece probe, central cooling.

Parameters:

spindle: MAS, 10000 rpm, ISO40

spindle motor: Siemens 1PH8 19.5 kW

control system: Heindenhain TNC620 HSCI, MC 8410 touch screen

workpiece/tool probe: YES

handweel: YES, Heidenhain HR510FS

measurement, rulers: Heidenhain LC415, EnDat 2.2

feed motors: Heidenhain QSY

central tool cooling: YES

external tool cooling: 10 bar, Grundfos

manual rinsing: spray gun at 10 bar

tool magazine: GIFU, 24-position drum

chip conveyor: NO, OPCE

inear guide: NSK

table clamping area: 1300 x 600 mm, T-slots 18.5 H7

max. table load: 700 kg

XYZW travel: 1000 x 600 x 660 mm

working air pressure: 6-7 bar

positioning accuracy: <0.01mm

total machine dimensions: W 3000 x L 2700 x H 2940 mm

total machine weight: approx. 5500 kg
